BIOFLEX Personal Therapy System

P120:

• Diodes: 120
• Effective Surface Area: 109cm2/16.9in2
• Total Optical Power: Red 709mW, Near Infrared 1420mW
• Visual and audio cues indicate when to change the array
• Power Density: Red 6.5mW/cm2, Infrared 13mW/cm2
• Wavelength: Red 660nm, Near Infrared 840nm
• Weight: 5 lbs
• Device size: 16 x 14 x 6″

P180:

• Diodes: 176
• Effective Surface Area: 163 cm2 / 25.26 in2
• Total Optical Power: Red 1165mW, Near Infrared 2331 mW
• Power Density: Red 7.15 mW/cm2, Infrared 14.3 mW/cm2
• Wavelength: Red 660nm, Near Infrared 840nm
• Weight: 5 lbs
• Device Size: 16 x 14 x 6″

• Controller Unit
• Treatment Array
• Power Cable
• Safety Glasses
• Carrying Case
• Product Manual
• Array Strap

• It is appropriate to read and understand the user manual. Failure to follow the instructions may result in complications and void the product warranty.
• Ensure that the system is electrically rated to operate with the alternating current power available in your location. Call BIOFLEX® Service for additional assistance.
• Connecting electrical equipment to a power bar effectively leads to creating a Medical Electrical System and the result can be a reduced level of safety (see IEC 60601-1).
• Use of accessories, detachable parts, and materials other than those provided with the system is not allowed and may be unsafe. Do not connect equipment other than what is provided with the system.
• Warning: Do not attempt to modify or open any part of the system. No modification of this equipment is allowed.
• The system is intended to be used externally over the skin only. Do not treat over compromised skin, mucous membranes, or over the eyes.
• Do not use the system over the eyes. It is inappropriate to do this as it may irritate or even damage the eyes.
• Avoid looking directly into the LED beam or staring at its bright reflections.
• Use dark glasses if your eyes are sensitive to the light emanating from the LED array or while treating upper body areas.
• Keep the system away from radiators and heat sources. Do not block any ports or cooling vents.
• Prolonged exposure to direct sunlight or excessive exposure to lint or dust is not recommended and may accelerate deterioration of the system components.
• The device must be used in a dry environment and be kept away from moisture at all times.
• The system is not waterproof. Do not allow it to become wet, do not rinse under water, or use while bathing.
• The system will produce an audible signal when powered on. Ensure the audible signal is heard before operating the system.
• Do not cover the LED array during treatment. The top surface removes excess heat into the surrounding environment.
• All system cables should be periodically inspected for signs of deterioration. Do not use the system if any cables are damaged.
• Do not exert excessive pressure or twisting motions on the LED array as this may damage the system circuitry.
• Do not pull or wrap cables around the LED array too tightly.
• Strangulation Hazard: Long cords and straps. Do not wrap cords or straps around the neck.
• Do not use the system while operating a vehicle or machinery.
• Do not use the system as a passenger in a vehicle. The bright light may distract the driver.
• Do not leave the device unattended while in operational mode.
• Keep out of reach of pets, pests, and children. Do not let young children use the system unattended.
• The system is designed for a service life of 10 years assuming that recommendations for annual calibration and maintenance are followed.
• Follow applicable local medical and electronic equipment disposal regulations and acts, including the Waste Electrical and Electronic Equipment Directive (WEEE Directive), if applicable.
